Design and manufacture standard: API 6D
Flange connecting end: ASME B16.5/ASME B16.47
Wall thickness: ASME B16.34
Fireproof design: API 607
Inspection and test: API 6D
Pressure and temperature standard: ASME B16.34
Nominal size: 1/2″～NPS 48"
Nominal pressure: PN1.0-42.5Mpa, ANSI CLASS 150-2500
Download
Product Detail
Main stainless steel: CF8, CF3, CF8M, CF3M, F304, F316, F304L, F316L, F51, F53, F55 etc.
Valve seat material: PTFE, RPTFE, NYLON, DEVLON, Derlin, PEEK, PPL, HNBR, FKM or metal hard seal etc.
Operation: handle, lever, worm gear, electrical actuator, pneumatic actuator, pneumatic- hydraulic actuator, electro-hydraulic actuator, etc.
